Midas DL32 Digital I/O Stage Box

Midas DL32 Digital I/O Stage Box

The Midas DL32 is a high-performance digital stage box designed for live sound and installation applications. It features 32 remote-controllable MIDAS PRO microphone preamps and 16 balanced analog line outputs, all integrated into a rugged 3U rack-mount unit.
This stage box offers ultra-low latency networked audio via dual AES50 SuperMAC ports, plus ULTRANET connectivity, ADAT optical outputs and AES/EBU digital outputs — making it ideal for both FOH and onstage monitor systems. SGS Sistēmas+1
Whether you’re running a live band, touring rig, fixed installation or broadcast chain, the DL32 gives you class-leading mic preamps, flexible I/O and networked signal distribution in a compact, sturdy format.

Key Features

• 32 MIDAS PRO series mic preamps with switchable +48 V phantom power — high headroom, ultra-clean gain.
• 16 electronically balanced low-impedance analog line outputs (XLR) for monitors or FOH returns.
• Dual AES50 SuperMAC ports (Neutrik etherCON) for ultra-low latency digital audio networking (up to 48 channels per port) via shielded Cat-5e cable (up to 100 m).
• ULTRANET port (RJ45) for personal monitoring integration (e.g., P16 systems) and Turbosound iQ speaker connectivity.
• Dual ADAT (optical Toslink) outputs for 16-channel optical digital output chain.
• AES/EBU digital outputs (2×) for direct digital connection in large rigs.
• “Mute All” front-panel switch for stage setup and safety.
• Rack-mount 19″, 3U chassis, with auto-range universal power supply (100-240V) and designed/engineered in England
